Robot battery pack

48V 100Ah Battery Pack for AGV / Robot

48V 100Ah Battery Pack for AGV / Robot

Product InformationItemSpecificationBattery type14S/48V/20AhModel no.14S20Ah-PC01-AChemistryNCM/NCANominal Voltage51.8VNomina...

Product Information

Item

Specification

Model no.

15S100Ah-PC03-A

Battery type

15S1P/48V/100Ah

Nominal Voltage

48V

Nominal Capacity

100Ah

Charge Voltage

54.75V

Charge Current

50A

Discharge Current

100A

Internal Resistance

≤30mΩ

Weight

42.0Kg±3.0Kg

Size

L600mm*W330mm*H160mm

BMS

include BMS

BMS Protection

Short-circuit   protection, over-charge protection, over-discharge protection, over-current   protection, temperature protection and keep the battery power balance.

Communication

RS485&RS232

Product Advantages

1. Brand guarantee:Use power type high rate brand cell

3. Long life cycle: >1500 Times

4. System safety: Equipped with intelligent BMS to monitor battery status and

Application Area

48V 20Ah Battery Pack for AGV / Robot(图1)     48V 20Ah Battery Pack for AGV / Robot(图2)     48V 20Ah Battery Pack for AGV / Robot(图3)

              Service robot                                            Fire-fighting robot                                           Inspection robot
